Dynablade/NeoPixel Connector EWxAK470 (blade side)

2,90 taxes inc.

196 in stock

SKU: EW-PCB_NPIX_BS_V1 Category:

Description

This product is a collaboration between EW and AK470
This is the blade side pcb for dynablades / neopixel blades.
Compatible with blade id feature.
With data line resistor pads.

Package contains PCB and 4 resistors :

0 ohm : to bridge Data line without resisting it
220 ohm : for Data line resisting
20 K ohm : for blade id feature
100 K ohm : for blade id feature

Pads are ENIG coating, for better contact surfaces. See HAL vs ENIG

Additional information

Weight 0.005 kg
Dimensions 2 × 2 × 0.1 cm
